Centro Di Lavoro Verticale Mikron VCP 1000
Technical specifications
| CNC Model | Heidenhain |
| CNC version | TNC 426 |
| Spindle Taper toolholders | iso 40 |
| Power spindle | 22 Kw |
| RPM | 12000 |
| Number of tools | 30 |
| X-axis travel | 1000 mm |
| Y-axis travel | 750 mm |
| Z-axis travel | 750 mm |
| Rapid linear axis feeds X Y Z | 30 m/min |
| Table dimension | 1100 x 700 mm |
| Guide | Linear guide |
| High coolant pressure | yes |
| Pressure value | 30 bar |
| System with external tank with filter | yes |
| Cheap conveyor | Hinged Belt |
Basic information
| Code | 71CE51 |
| Level of machine tool |
IB Product
|
| Brand | Mikron |
| Model | VCP 1000 |
| Construction year | 1999 |
Dimensions and weight
| Length | 2700 mm |
| Width | 4000 mm |
| Height | 3200 mm |
| Weight | 9500 Kg |
